Vistas:0 Autor:Editor del sitio Hora de publicación: 2026-03-23 Origen:Sitio
Adjunto la información del compresor danfoss.
| Modelo | Refrigerante/Frecuencia | 60 Hz Capacidad de refrigeración nominal TR | Capacidad de refrigeración nominal W | Capacidad de refrigeración nominal Btu/h | Potencia de entrada W | Coeficiente COP W/W | EER Btu/h/W | cm³/rev | Displ. ¹ m³/h | carga de aceite dm³ | N.W ² kg |
|---|---|---|---|---|---|---|---|---|---|---|---|
| LLZ013 | 50 Hz R448A/R449A* | 4 | 2048 | 6990 | 2106 | 0.97 | 3.32 | 67.4 | 11.7 | 1.64 | 43 |
| LLZ015 | 50 Hz R448A/R449A* | 5 | 2605 | 8890 | 2642 | 0.99 | 3.37 | 83.5 | 14.5 | 1.64 | 43 |
| LLZ018 | 50 Hz R448A/R449A* | 6 | 3084 | 10525 | 2964 | 1.04 | 3.55 | 97.6 | 17.0 | 1.64 | 44 |
| LLZ024 | 50 Hz R448A/R449A* | 8 | 3846 | 13126 | 3542 | 1.09 | 3.71 | 120.2 | 20.9 | 2.51 | 47 |
| LLZ034 | 50 Hz R448A/R449A* | 10 | 5480 | 18704 | 4684 | 1.17 | 3.99 | 168.7 | 29.4 | 2.51 | 52 |
| LLZ013 | 50Hz R455A | 4 | 1980 | 6757 | 1980 | 1.00 | 3.41 | 67.4 | 11.7 | 1.64 | 43 |
| LLZ015 | 50Hz R455A | 5 | 2486 | 8481 | 2379 | 1.04 | 3.57 | 83.5 | 14.5 | 1.64 | 43 |
| LLZ018 | 50Hz R455A | 6 | 3222 | 10995 | 2739 | 1.18 | 4.01 | 97.6 | 17.0 | 1.64 | 44 |
| LLZ024 | 50Hz R455A | 8 | 3755 | 12812 | 3331 | 1.13 | 3.85 | 120.2 | 20.9 | 2.51 | 47 |
| LLZ034 | 50Hz R455A | 10 | 5283 | 18026 | 4643 | 1.14 | 3.88 | 168.7 | 29.4 | 2.51 | 52 |
| LLZ013 | 60 Hz R448A/R449A* | 4 | 3314 | 11310 | 2737 | 1.21 | 4.13 | 67.4 | 14.2 | 1.64 | 43 |
| LLZ015 | 60 Hz R448A/R449A* | 5 | 4097 | 13983 | 3416 | 1.20 | 4.09 | 83.5 | 17.5 | 1.64 | 43 |
| LLZ018 | 60 Hz R448A/R449A* | 6 | 4900 | 16723 | 3815 | 1.28 | 4.38 | 97.6 | 20.5 | 1.64 | 44 |
| LLZ024 | 60 Hz R448A/R449A* | 8 | 6046 | 20636 | 4580 | 1.32 | 4.51 | 120.2 | 25.3 | 2.51 | 47 |
| LLZ034 | 60 Hz R448A/R449A* | 10 | 8531 | 29116 | 5928 | 1.44 | 4.91 | 168.7 | 35.4 | 2.51 | 52 |
| LLZ013 | 60Hz R455A | 4 | 3171 | 10821 | 2476 | 1.28 | 4.37 | 67.4 | 14.2 | 1.64 | 43 |
| LLZ015 | 60Hz R455A | 5 | 3946 | 13464 | 2961 | 1.33 | 4.55 | 83.5 | 17.5 | 1.64 | 43 |
| LLZ018 | 60Hz R455A | 6 | 4717 | 16094 | 3393 | 1.39 | 4.74 | 97.6 | 20.5 | 1.64 | 44 |
| LLZ024 | 60Hz R455A | 8 | 5791 | 19758 | 4097 | 1.41 | 4.82 | 120.2 | 25.3 | 2.51 | 47 |
| LLZ034 | 60Hz R455A | 10 | 8255 | 28165 | 5613 | 1.47 | 5.02 | 168.7 | 35.4 | 2.51 | 52 |
| Modelo | caballos de fuerza | Capacidad de refrigeración nominal W | Capacidad de refrigeración nominal Btu/h | Potencia de entrada kW | COP P/P | EER Btu/h/W | Volumen barrido cm³/rev | Desplazamiento m³/h | Carga de aceite Litros | Peso neto kg | Refrigerante |
| MLZ015 | 2 | 3300 | 11300 | 1.75 | 1.89 | 6.45 | 33.8 | 5.9 | 1.14 | 31 | R404A |
| MLZ019 | 2.5 | 4500 | 15400 | 2.16 | 2.06 | 7.03 | 43.5 | 7.6 | 1.14 | 31 | R404A |
| MLZ021 | 3 | 4700 | 16000 | 2.27 | 2.08 | 7.1 | 46.2 | 8 | 1.14 | 31 | R404A |
| MLZ026 | 3.5 | 5800 | 19800 | 2.9 | 2 | 6.83 | 57.1 | 9.9 | 1.14 | 31 | R404A |
| MLZ030 | 4 | 7100 | 24200 | 3.35 | 2.11 | 7.2 | 68.8 | 12 | 1.73 | 41 | R404A |
| MLZ038 | 5 | 8400 | 28700 | 3.86 | 2.19 | 7.47 | 81 | 14.1 | 1.73 | 41 | R404A |
| MLZ045 | 6 | 10200 | 34800 | 4.81 | 2.11 | 7.2 | 98.6 | 17.2 | 1.73 | 41 | R404A |
| MLZ048 | 7 | 11100 | 37900 | 5.17 | 2.14 | 7.3 | 107.5 | 18.7 | 1.73 | 41 | R404A |
| MLZ058 | 7.5 | 13000 | 44400 | 6.08 | 2.13 | 7.27 | 126 | 21.9 | 2.66 | 46 | R404A |
| MLZ066 | 9 | 15100 | 51500 | 7.01 | 2.15 | 7.34 | 148.8 | 25.9 | 2.66 | 47 | R404A |
| MLZ076 | 10 | 17300 | 59000 | 7.93 | 2.18 | 7.44 | 162.4 | 28.3 | 2.66 | 47 | R404A |
| MLZ015 | 2 | 2000 | 6800 | 1.02 | 1.95 | 6.66 | 33.8 | 5.9 | 1.14 | 31 | R134a |
| MLZ019 | 2.5 | 2500 | 8500 | 1.28 | 1.98 | 6.76 | 43.5 | 7.6 | 1.14 | 31 | R134a |
| MLZ021 | 3 | 2700 | 9200 | 1.33 | 2.04 | 6.96 | 46.2 | 8 | 1.14 | 31 | R134a |
| MLZ026 | 3.5 | 3300 | 11300 | 1.62 | 2.06 | 7.03 | 57.1 | 9.9 | 1.14 | 31 | R134a |
| MLZ030 | 4 | 4000 | 13700 | 1.93 | 2.09 | 7.13 | 68.8 | 12 | 1.73 | 41 | R134a |
| MLZ038 | 5 | 4700 | 16000 | 2.34 | 2.02 | 6.89 | 81 | 14.1 | 1.73 | 41 | R134a |
| MLZ045 | 6 | 5900 | 20100 | 2.69 | 2.17 | 7.41 | 98.6 | 17.2 | 1.73 | 41 | R134a |
| MLZ048 | 7 | 6200 | 21200 | 2.91 | 2.14 | 7.3 | 107.5 | 18.7 | 1.73 | 41 | R134a |
| MLZ058 | 7.5 | 7400 | 25300 | 3.61 | 2.06 | 7.03 | 126 | 21.9 | 2.66 | 46 | R134a |
| MLZ066 | 9 | 8600 | 29400 | 4.1 | 2.1 | 7.17 | 148.8 | 25.9 | 2.66 | 47 | R134a |
| MLZ076 | 10 | 9600 | 32800 | 4.67 | 2.06 | 7.03 | 162.4 | 28.3 | 2.66 | 47 | R134a |
| MLZ015 | 2 | 3200 | 11000 | 1.68 | 1.91 | 6.52 | 33.8 | 5.9 | 1.14 | 31 | R448A |
| MLZ019 | 2.5 | 4200 | 14300 | 2.11 | 1.99 | 6.79 | 43.5 | 7.6 | 1.14 | 31 | R448A |
| MLZ021 | 3 | 4400 | 15000 | 2.23 | 1.97 | 6.73 | 46.2 | 8 | 1.14 | 31 | R448A |
| MLZ026 | 3.5 | 5500 | 18700 | 2.78 | 1.97 | 6.72 | 57.1 | 9.9 | 1.14 | 31 | R448A |
| MLZ030 | 4 | 6600 | 22500 | 3.17 | 2.08 | 7.09 | 68.8 | 12 | 1.73 | 41 | R448A |
| MLZ038 | 5 | 7800 | 26600 | 3.64 | 2.14 | 7.3 | 81 | 14.1 | 1.73 | 41 | R448A |
| MLZ045 | 6 | 9700 | 33000 | 4.58 | 2.11 | 7.21 | 98.6 | 17.2 | 1.73 | 41 | R448A |
| MLZ048 | 7 | 10400 | 35500 | 5.06 | 2.06 | 7.02 | 107.5 | 18.7 | 1.73 | 41 | R448A |
| MLZ058 | 7.5 | 12200 | 41700 | 5.57 | 2.19 | 7.48 | 126 | 21.9 | 2.66 | 46 | R448A |
| MLZ066 | 9 | 14200 | 48500 | 6.75 | 2.11 | 7.21 | 148.8 | 25.9 | 2.66 | 47 | R448A |
| MLZ076 | 10 | 15200 | 51700 | 7.61 | 1.99 | 6.8 | 162.4 | 28.3 | 2.66 | 47 | R448A |
